LGS326

The 26-Port Smart Gigabit Switch delivers business-class management, security, and performance with IPv6 Support, QoS, Spanning Tree Protocol, and DHCP snooping.

Proven Performance | Easy Configuration | Advanced Security | IPv6 Support | Enhanced QoS | EEE 802.3az | Jumbo Frame 9K

Specifications:

Brand: Linksys | Total Ports: 26GE | Copper Ports (RJ45): g01–g24 | Combo Ports (RJ45+SFP): 2 (g25, g26) | Memory: 128MB

Performance:

Switching Capacity: 52 Gbps | Forwarding Rate: 38.69 Mpps | HOL Blocking Prevention: Yes

Power:

Input: 100–240V, 50-60Hz, 0.7A max | Consumption: 110V: 17.62W | 220V: 17.72W

VLAN:

Port-based, 802.1q tag-based, Management, Guest, Dynamic (RADIUS + 802.1x) | Auto Voice VLAN: Yes

QoS:

Scheduling: Priority Queuing, WRR | CoS: Port-based, 802.1p, IPv4/v6 DSCP | Priority Levels: 4 hardware queues

Security:

802.1x RADIUS | DHCP Snooping | IP-MAC Binding | Management Access Control | Port Security (Dynamic Lock & Locked MAC)

Spanning Tree:

IEEE 802.1d STP | IEEE 802.1w RSTP

Link Aggregation:

IEEE 802.3ad LACP | Up to 4 groups, 8 ports per group

IGMP Snooping:

v1/v2/v3 | 256 multicast groups

Storm Control:

Broadcast | Flooding | Multicast

Management:

Interface: HTTP, HTTPS | Other: Telnet CLI, DHCP Client, System Log, PING, Dual Images, SNTP, Config Backup via HTTP/TFTP

SNMP: v1, v2c | RMON: Embedded | Port Mirroring: Up to 4 ports | Firmware Upgrade: TFTP, HTTP/HTTPS

Green Power Mode: EEE+ | Short Reach | Energy Detect

Physical:

Dimensions: 440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.) | Weight: 2.424 kg (5.33 lbs.)

Temperature:

Operating: 0–50°C (32–122°F) | Storage: -40–70°C | Humidity: 10–90% RH (non-condensing)

Network Standards:

IEEE 802.1d | 802.1Q/p | 802.1X | 802.3 | 802.3ab | 802.3ad | 802.3az | 802.3u | 802.3x | 802.3z
